PMC PH-Hybrid
Eliminate the need for two proportioners with the one-size-fits-all PH-Hybrid. Delivering the versatility to spray Foam or Coatings and the reliability of the PH-2, the PH-Hybrid will help you increase profits! Great for residential and light commercial applications, this proportioner features a larger hydraulic reservoir for trouble-free operation in extreme heat and cold.
- Output: 28 lbs/min (12.70 kg/min)
- Max Working Pressure: 2,500 psi (138 bar)
- Max Hose Length:
- 210 ft (64 m) w/70V Trans
- 310 ft (94.5 m) w/90V Trans
- 410 ft (121.9 m) w/120V Trans
- Heater Wattage:
- 7,500 watts Total (Single htr)
- 9,000 watts Total (Single htr)
- 10,500 watts Total (Single htr)
- Hose Heating Power: 70 Volt, 90 Volt or 120 Volt
- Max Fluid Temperature: 190 °F (87.7 °C)
- Air Consumption @ 100 psi (6.9 bar): Not Applicable
- Main Voltage: 1 x 208-230V, 60 Hz
- Electrical @ 230V Single Phase:
- 66A–7,500W heaters
- 73A–9,000W heaters
- 79A–10,500W heaters
- 94A–14,000W heaters
- Main Voltage:
- 3 x 208-230V, 50/60 Hz
- 3 x 380V, 50/60 Hz
- Electrical @ 230V Three Phase:
- 39A–7,500W heaters
- 43A–9,000W heaters
- 47A–10,500W heaters
- 69A–14,000W heaters
- Dimensions: 44”w x 22”d x 54”h (111 cm x 55 cm x 137 cm)
- Weight 415 lbs (188 kg)
